ProArt B760 Creator WIFI



ProArt B760 Creator WIFI

CPU:
  • Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors
  • Supports Intel 10 nm CPU
  • Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
  • Chipset: Intel B760 Chipset
Memory:
  • 4 x DIMM slots, Max. 192GB, DDR5 Non-ECC, Un-buffered Memory
  • Dual Channel Memory Architecture
  • Supports Intel Extreme Memory Profile (XMP)
  • OptiMem II
Graphics:
  • 1 x HDMITM port
  • 1 x DisplayPort port
Expansion Slots:
  • Intel 14th & 13th & 12th Gen Processors:
  • 1 x PCIe 5.0/4.0/3.0 x16 slot
  • Intel B760 Chipset:
  • 1 x PCIe 4.0 x16 slot (supports x4 mode)
  • 1 x PCIe 3.0 x1 slot
Storage:
  • Total supports 3 x M.2 slots and 4x SATA 6Gb/s ports
  • Intel 14th & 13th & 12th Gen Processors
  • M.2_1 slot (Key M), type 2242/2260/2280/22110
  • Intel 14th & 13th & 12th Gen processors support PCIe 4.0 x4 mode.
Intel B760 Chipset:
  • M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 mode)
  • M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
  • 4 x SATA 6Gb/s ports
Ethernet:
  • 1 x Realtek 2.5Gb Ethernet
  • 1 x Intel 1Gb Ethernet
  • ASUS LANGuard
Wireless & Bluetooth:
  • Wi-Fi 6
  • 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
  • Supports 2.4/5GHz frequency band
  • Bluetooth v5.2
USB:
Rear USB (Total 9 ports):
  • 1 x USB 3.2 Gen 2 (10G) Type-C port
  • 4 x USB 3.2 Gen 1 (5G) ports (4 x Type-A)
  • 4 x USB 2.0 ports (4 x Type-A)
  • Front USB (Total 7 ports):
  • 1 x USB 3.2 Gen 2x2 (20G) connector (supports USB Type-C with 60W PD/QC4+)
  • 1 x USB 3.2 Gen 1 (5G) header supports additional 2 x USB 3.2 Gen1 ports
  • 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Audio:
  • Realtek 7.1 Surround Sound High Definition Audio CODEC
  • Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • Supports up to 24-Bit/192 kHz playback
  • Audio Features: Premium audio capacitors, Dedicated audio PCB layers, Audio cover, Unique de-pop circuit
Back Panel I/O Ports:
  • 1 x USB 3.2 Gen 2 port (1 x USB Type-C®)
  • 4 x USB 3.2 Gen 1 ports (4 x Type-A)
  • 4 x USB 2.0 ports (4 x Type-A)
  • 1 x DisplayPort
  • 1 x HDMITM port
  • 1 x Wi-Fi Module
  • 1 x Realtek  2.5Gb Ethernet port
  • 1 x Intel 1Gb Ethernet port
  • 5 x Audio jacks
  • 1 x Optical S/PDIF out port
Internal I/O Connectors:
Fan and Cooling related:
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header
  • 4 x 4-pin Chassis Fan headers
Power related:
  • 1 x 24-pin Main Power connector
  • 1 x 8-pin +12V Power connector
  • 1 x 4-pin +12V Power connector
  • 1 x 6-pin PD_12V Power connector
Storage related:
  • 3 x M.2 slots (Key M)
  • 4 x SATA 6Gb/s ports
USB:
  • 1 x USB 3.2 Gen 2x2 (20G) connector (supports USB Type-C with 60W PD/QC4+)
  • 1 x USB 3.2 Gen 1 (5G) header supports additional 2 x USB 3.2 Gen1 ports
  • 2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous:
  • 3 x Addressable Gen 2 headers
  • 1 x AURA RGB header
  • 1 x Clear CMOS header
  • 1 x COM Port header
  • 1 x Front Panel Audio header (AAFP)
  • 1 x SPI TPM header (14-1pin)
  • 1 x 20-5 pin System Panel header
  • 1 x Thermal Sensor header
  • 1 x Thunderbolt  header
  • BIOS:128 Mb
  • Manageability: WOL by PME, PXE
Accessories:
  • Cables:2 x SATA 6Gb/s cables
Miscellaneous:
  • 1 x ASUS Wi-Fi moving antennas
  • 2 x M.2 Rubber packages
  • 1 x ProArt ruler
  • 1 x Q-connector
Documentation:
  • 1 x ACC Express Activation Key Card
  • 1 x User guide
  • Operating System: Windows 11 64-bit, Windows 10 64-bit
Form Factor:
  • ATX Form Factor:12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
