ProArt Z890 Creator WIFI



ProArt Z890 Creator WIFI

CPU:
  • Support Intel Core Ultra Processors (Series 2), LGA1851
  • Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
  • Chipset: Intel Z890 Chipset
Memory:
  • 4 x DIMM slots, max. 192GB, DDR5
  • Support up to 9066+MT/s (OC), Non-ECC, Un-buffered and Clocked Unbuffered DIMM (CUDIMM)*
  • Dual channel memory architecture
  • Supports Intel Extreme Memory Profile (XMP) memory module
  • ASUS Enhanced Memory Profile III (AEMP III)
  • Support DIMM Fit
  • Support DIMM Flex
Graphics:
  • 1 x HDMI port
  • 2 x Intel Thunderbolt 5 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs
  • 1 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs
Expansion Slots:
Intel Core Ultra Processors (Series 2):
  • 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)
  • Intel Z890 Chipset
Storage:
  • Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports
  • Intel Core Ultra Processors (Series 2):
  • M.2_1 slot (Key M), type 2242/2260/2280/22110  (supports PCIe 5.0 x4 mode)
  • M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
Intel Z890 Chipset:
  • M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  • M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 modes)
  • M.2_5 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
  • 4 x SATA 6Gb/s ports
Ethernet:
  • 1 x Marvell AQtion 10Gb Ethernet
  • 1 x Intel 2.5Gb Ethernet
  • ASUS LANGuard
Wireless & Bluetooth:
  • Wi-Fi 7
  • 2x2 Wi-Fi 7 (802.11be)
  • Supports 2.4/5/6GHz frequency band
  • Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate.
  • Bluetooth v5.4
USB:
  • Rear USB (Total 10 ports):
  • 2 x Thunderbolt 5 ports (2 x USB Type-C)
  • 1 x Thunderbolt 4 port (1 x USB Type-C)
  • 6 x USB 10Gbps ports (6 x Type-A )
  • 1 x USB 2.0 port (1 x Type-A )
Front USB (Total 5 ports):
  • 1 x USB 20Gbps (supports USB Type-C)
  • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  • 1 x USB 2.0 header supports 2 additional USB 2.0 ports
  • USB Type-C power delivery output: max. 5V/3A
Audio:
  • Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC:
  • - Impedance sense for front and rear headphone outputs
  • - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  • - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
  • - Supports up to 32-Bit/192 kHz playback Audio Features
  • - Gold-plated audio jacks
  • - Premium audio capacitors
  • - Dedicated audio PCB layers
Back Panel I/O Ports:
  • 2 x Thunderbolt 5 USB Type-C ports
  • 1 x Thunderbolt 4 USB Type-C port
  • 6 x USB 10Gbps ports (6 x Type-A)
  • 1 x USB 2.0 port (1 x Type-A)
  • 1 x DisplayPort (Input only)
  • 1 x HDMI port
  • 1 x Wi-Fi module1 x Marvell AQtion 10Gb Ethernet port
  • 1 x Intel 2.5Gb Ethernet port
  • 2 x Gold-plated audio jacks
  • 1 x BIOS FlashBack button
Internal I/O Connectors:
Fan and Cooling Related:
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header
  • 5 x 4-pin Chassis Fan headers
Power Related:
  • 1 x 24-pin Main Power connector
  • 2 x 8-pin +12V CPU Power connector
Storage Related:
  • 5 x M.2 slots (Key M)
  • 4 x SATA 6Gb/s ports
USB:
  • 1 x USB 20Gbps connector (supports USB Type-C )
  • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  • 1 x USB 2.0 header supports 2 additional USB 2.0 ports
Miscellaneous:
  • 3 x Addressable Gen2 headers
  • 1 x Clear CMOS button
  • 1 x COM Port header
  • 1 x CPU Over voltage jumper
  • 1 x Chassis Intrusion header
  • 1 x Front Panel Audio header (F_AUDIO)
  • 1 x SPI TPM header (14-1 pin)
  • 1 x 10-1 pin Front System Panel header
  • 1 x Thermal Sensor header
Remote Management Features:
  • IT Management software supported: ASUS Control Center Express(ACCE)
BIOS:
  • 256 Mb Flash ROM, UEFI AMI BIOS
Manageability:
  • WOL by PME, PXE
Accessories:
  • Cables:2 x SATA 6Gb/s cables
Miscellaneous:
  • 1 x ASUS WiFi Q-Antenna
  • 1 x Q-connector
  • 2 x M.2 Q-Latch packages
  • 2 x M.2 rubber packages
  • 1 x ProArt accessory bag
Documentation:
  • 1 x ACC Express activation key card
  • 1 x Quick start guide
  • Operating System: Windows 11  (22H2 & later)
Form Factor:
  • ATX Form Factor:12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
