PRIME Z890 P WIFI CSM



PRIME Z890 P WIFI CSM

CPU:
  • Supports Intel Core Ultra Processors (Series 2), LGA1851
  • Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Chipset:
  • Intel Z890 Chipset
Memory:
  • 4 x DIMM slots, max. 192GB, DDR5
  • Support up to 8666+MT/s (OC),Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)
  • Dual channel memory architecture
  • DIMM Fit
  • Supports Intel Extreme Memory Profile (XMP) memory module
  • ASUS Enhanced Memory Profile III(AEMPIII)

Graphics:
  • 1 x DisplayPort
  • 1 x HDMITM port
  • 1 x Intel Thunderbolt 4 port (USB Type-C) supports DisplayPort and Thunderbolt video outputs
Expansion Slots:
  • Intel Core Ultra Processors (Series 2) 1 x PCIe 5.0 x16 slot
  • Intel Z890 Chipset 2 x PCIe 4.0 x16 slots (support x4 mode) 1 x PCIe 4.0 x16 slot (supports x1 mode)
Storage
  • Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
  • intel Core Ultra Processors (Series 2)
  • M.2_1 slot (Key M), type 2280/22110 (supports PCIe 5.0 x4 mode)
  • M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
  • Intel Z890 Chipset
  • M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
  • M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
  • 4 x SATA 6Gb/s ports
Ethernet:
  • 1 x Realtek 2.5Gb Ethernet
  • ASUS LANGuard
  • Wireless & Bluetooth
  • Wi-Fi 7
  • 2x2 Wi-Fi 7 (802.11be)
  • USB
  • Rear USB (Total 8 ports)
  • 1 x Thunderbolt 4 port (1 x USB Type-C)
  • 1 x USB 10Gbps port (1 x Type-A)
  • 2 x USB 5Gbps ports (2 x Type-A)
  • 4 x USB 2.0 ports (4 x Type-A)
  • Front USB (Total 9 ports)
  • 1 x USB 10Gbps connector (supports USB Type-C)
  • 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
  • 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio
  • Realtek 7.1 Surround Sound High Definition Audio CODEC
  • - Supports: Jack-detection,
  • Multi-streaming, Front Panel Jack-retasking
  • - Supports up to 24-Bit/192 kHz playback
  • Audio Features: Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers
Back Panel I/O Ports:
  • 1 x Thunderbolt 4 USB Type-C port
  • 1 x USB 10Gbps port (1 x Type-A)
  • 2 x USB 5Gbps ports (2 x Type-A)
  • 4 x USB 2.0 ports (4 x Type-A)
  • 1 x DisplayPort
  • 1 x HDMITM port
  • 1 x Wi-Fi module
  • 1 x Realtek 2.5Gb Ethernet port
  • 3 x Audio jacks
  • 1 x BIOS FlashBack button
Internal I/O Connectors:
Fan and Cooling related:
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header
  • 4 x 4-pin Chassis Fan headers
Power related:
  • 1 x 24-pin Main Power connector
  • 2 x 8-pin +12V CPU Power connector
Storage related:
  • 4 x M.2 slots (Key M)
  • 4 x SATA 6Gb/s ports
USB:
  • 1 x USB 10Gbps connector (supports USB Type-C)
  • 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports
  • 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous:
  • 3 x Addressable Gen2 headers
  • 1 x Aura RGB header
  • 1 x Clear CMOS header
  • 1 x COM Port header
  • 1 x Front Panel Audio header (F_AUDIO)
  • 1 x S/PDIF Out header
  • 1 x SPI TPM header (14-1pin)
  • 1 x 10-1 pin Front Panel System header
  • 1 x Thunderbolt (USB4) header
Special Features:
  • ASUS 5X PROTECTION III: DIGI+ VRM (- Digital power design with DrMOS), LANGuard, Overvoltage Protection, SafeSlot, Stainless-Steel Back I/O
  • ASUS Q-Design: M.2 Q-Latch, PCIe Slot Q-Release, Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED Core, Q-Slot
  • ASUS Thermal Solution: M.2 heatsink, VRM heatsink design
  • ASUS EZ DIY: BIOS FlashBack button, BIOS FlashBack LED, ProCool, Pre-mounted I/O shield
  • Aura Sync:Aura RGB header, Addressable Gen2 headers
Accessories:
  • Cables:2 x SATA 6Gb/s cables
Miscellaneous:
  • 1 x ASUS WiFi Q-Antenna
  • 1 x M.2 rubber package
  • 2 x Screw packages for M.2 SSD
  • Documentation:1 x Quick start guide
  • Operating System:Windows 11 (22H2 & later)
Form Factor:
  • ATX Form Factor:12 inch x 9.6inch ( 30.5 cm x 24.4 cm )
